Shielded Flexible Cable

TC VN/PVC, 2 C #10 Str BC, PVC Ins E2, OS, Blk PVC Jkt, 600V TC 90C Dry/Wet SUN RES DIR BUR

UL Type TC (1277) PVC-Nylon/PVC, 2 Conductor 10AWG (7x18H) Bare Copper, PVC-NYL Insulation E2 Color Code, Overall Beldfoil® Shield, Black PVC Outer Jacket, 600V TC 90C Dry/Wet SUN RES DIR BUR

Shielded Flexible Cable

“600V/90°C EMI-proof power solution for harsh environments. UV-resistant, direct-burial ready, with oil-flex conductors for robotics/industrial automation. ​UL/CE certified + free samples!”



Category:
Shielded Flexible Cable
Shielded Flexible Cable

Click to view more products

Specifications

Product Overview
Suitable Applications Power and Control Applications up to 600V; Class 1 Division 2 Hazardous Locations; Recommended Cable Gland Belden BTC075A0551RA
Construction Details
Conductor
Element No. of Elements Size Stranding Material
Conductor(s) 2 10 AWG 7×18 BC – Bare Copper
Insulation
Element Material Nom. Thickness Nom. Insulation Diameter Color Code
Conductor(s) PVC/Nylon – Polyvinyl Chloride + Nylon 0.027 in (0.69 mm) 0.166 in mm Black, Red
Outer Shield
Shield Type Material Coverage
Tape Bi-Laminate (Alum+Poly) 100%
Outer Jacket
Material Nom. Thickness Nom. Diameter Ripcord
PVC – Polyvinyl Chloride 0.048 in (1.2 mm) .432 in Yes
Overall Cable Diameter (Nominal) 0.432 in
Electrical Characteristics
Electricals
Nom. Conductor DCR Max. Current
1.06 Ohm/1000ft 40 Amps per Conductor at 30ºC
Voltage
UL Voltage Rating
600 V
Mechanical Characteristics
Temperature
UL Temperature Operating
90°C Dry, 90°C Wet -30°C To +90°C
Bend Radius
Stationary Min. Installation Min.
5.184 in (131.7 mm) 5.184 in
Max. Pull Tension 263.6 lbs (119.6 kg)
Bulk Cable Weight 133 lbs/1000ft
Standards and Compliance
Environmental Suitability Indoor, Outdoor, Sunlight Resistance, UV Resistance, Burial
Flammability / Reaction to Fire UL1685 UL Loading, FT4, IEEE 1202 FT4
NEC / UL Compliance Article 336, TC, THWN-2
European Directive Compliance EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
Plenum Number ICEA S-73-532, S-95-658, S-61-402
